ELECTRICALLY HEATED
SERIES 212 FLUOROPOLYMER TFE CORE HOSES

---

LP212 LOW PRESSURE
These high temperature models feature a built-in electric heating element that provides heat up to 450 degrees (232 degrees C). The TFE fluoropolymer core is reinforced with a tin/copper overbraid Construction includes thermal insulation and scuff resistant jacket. Available with most standard couplings, they are supplied hydraulically and electrically complete. They offer flexibility, durability, chemical inertness and high resistance to corrosion over their entire temperature range.

---

212 HIGH PRESSURE
Model 212 Heat/Line Hoses have the same TFE fluoropolymer core, heating element, electrical insulation and basic construction as our LP212 models above, but feature a stainless steel braid of greater density. This provides higher working pressures, and rugged construction. The flexibility of this braiding, combined with the inherent flexibility of the fluoropolymer core, produces exceptional durability, and facilitates ease of routing and handling as well.

---

212 CONVOLUTED CORE
These hoses feature a helical convoluted fluoropolymer core with a reinforced stainless steel wire braid. Designed to operate up to 400 degrees F (204 degrees C), they come with double thermal insulation and high resistance to corrosion over their entire temperature range. Available with most standard couplings, they are supplied hydraulically and electrically complete.

---

*DuPont Trademark

DOWNLOAD SERIES 212 OPERATING INSTRUCTIONS
